R.O Plant

Product Details:

We are ranked as a dominating Manufacturer, Exporter, Distributor, Trader and Supplier ofPackaged Drinking Water Plant.It is used for packaged drinking water in different capacities.

• Our experts can manufacturePackaged Drinking Water Plantin different functional capacities at most affordable prices.
• In order to provide flawless plant, this is tested against various norms of the arena.
• Due to all, it is massively applauded and demanded among the valued customers of the arena.

Additional Information:

• Delivery Time: 40 to 50 days

Product Details:

Product Description

The RO System works on the principle of Reverse osmosis, also known as hyper-filtration. One of the finest techniques for treating water, reverse osmosis eliminates contaminants from water thus making it fit for drinking purpose and other commercial and industrial applications. The RO system is provided with sediment pre-filter and an activated carbon filter as the membranes are degraded by chlorine, bacterial attack, manganese, hydrogen sulfide and iron. Advanced models of RO Systems are also attached with water softeners.

Available as:

• Commercial Reverse Osmosis System
• Residential Reverse Osmosis System
• Portable Reverse Osmosis System
• Heavy Duty residential Reverse Osmosis System

Working

• Stage 1: Removes dirt, sediment, sand and other physical particles
• Stage 2: Granular Carbon Filter which reduces chlorine, organics, odor, smell and turbidity from water
• Stage 3: Block Carbon Filter that further reduces chlorine, odors and other chemicals
• Stage 4: Reverse Osmosis Membrane in which bacteria, heavy metals, salt, bad mineral substances and other dissolved matter and chemical drugs are removed from water
• Stage 5: Rear anti-bacteria activated carbon filter that improve the taste of water

Technical specifications

• Allowed pressure for source water: 0.1-0.3Mpa
• Work temperature: 5-40? Max of original water
• TDS: 1000ppm
• Output: 100-400G/Day
• Flush Type: Auto flush
• Fitting: Common fitting or quick connect fitting
• Volume of pressure storage tank: 11G Rated voltage
• Frequency: AC220V/50Hz
• Rated power: 50W
• Precision of purification: 0.0001um
• Transformer: 24V(220V)

Application areas:

RO Systems are used in Homes, offices, hospitals, clinics, Nursery homes, beauty salons, gyms, schools, restaurants and shops.

Product Details:

Process of Industrial RO Plant
Raw Water Pump:-

• To generate the pressure for down the line system.

Pressure Sand Filter (PSF):

• The water is first filtered by Pressure sand filter Unit for removal of suspended matters and turbidity.

Activated Carbon Filter(ACF):

• To remove Color, Odor, Chlorine, Oil & Grease from the raw water.

Micron cartridge Filter(MCF):

• These are Pressure Vessels Fitted internally with spun or pleated cartridge element which removes micron sized particles.

Antiscalant Dosing System:

• To prevent membrane from scaling (hardness).

High Pressure Pump:

• A high pressure pump is provided for supplying the feed water to RO System at high pressure of 10 - 12 kg/cm2.

Desalination System by RO Membrane Element:

• A Reverse Osmosis System rejects 90-95% of Total Dissolved Solids (TDS).

Storage of Treated(Pure) Water:

• To store Treated (pure) water in tank.

Other Information:

• Pay Mode Terms: T/T (Bank Transfer)
• Minimum Order Quantity: 1 Set
• Production Capacity: 5 Machine in a month
• Delivery Time: 15 - 20 days
• Packaging Details: Wooden Box Packing

Product Details:

We offer Water Treatment Plants to our clients. with s.s skid Capacity 250 ltr

Additional Information:

• Delivery Time: 15 days

Product Details:

We offer Industrial RO Plantto our clients.

Product Details:

Shiv Shakti Enterprise are the leading manufacturers and suppliers The project set up includes following units

Features

• Water Treatment Plant
• Filling Line for CSD or Juice Bottles
• Blowing Machines for PET Bottles
• Pouch Form, Fill & Seal Machine
• Jars Washers, Rinser and Filling Line
• Cup Rinsing, Filling & Foil Sealing Machine
• Batch Printers
• Packing Tables and Shrink Wrap machine

Machines are available for various bottle volumes and are available for capacities ranging from 1500 Bottles per hour in semi auto range and 2000 Bottles per hour up to 20000 bottles per hour in fully auto range.

Other Information

• Pay Mode Terms T/T (Bank Transfer)
• Minimum Order Quantity 1 Set
• Production Capacity 5 set in a month
• Delivery Time 20 - 35 days
• Packaging Details wooden Box Packing

Product Details:

We are offering R.O Plant to our client.
F.R.P R.O plant capacity - 2000 LPH

Product Details:

Industrial reverse osmosis system plant is best suited for small and large scale industries. This type of reverse osmosis plant can be configured easily as per the individual requirements of output water. It produces high-quality demineralised water for various industrial applications. A systematic programme is integrated in the plant for studying the chemistry of water. Depending upon the contamination level of water, the RO plant itself selects the most suitable membrane configuration to provide a plant which gives a low water-rejection rate.

Working:

• The input stream water is first passed through Pressure sand filter Unit
• Removal of suspended matters and turbidity from water
• Filtered water is then passed through activated carbon filter
• Color, odor, chlorine, oil& grease get removed from raw water
• For removing micron sized particle, the water is then passed through micron cartridge filter
• The purified water is then stored in a storage tank with disinfection units

System Efficiency:

• Percentage ionic rejection >96%
• Percent recovery 50-75%

Application Areas:

• Effluent and wastewater purification
• Food processing industry
• Car washing
• Hydrogen production
• Fruit syrup production
• Beverage industries

Product Details:

FRP R.O Plant finds wide application in many commercial establishments and industries for various applications. These RO plants are the cost-effective solution for producing high-quality demineralized water with low water rejection rate. All these reverse osmosis plants are available in varieties of construction like FRP, Stainless steel and MSRL. Extensively used in the food and beverage industry, pharmaceutical and electronics industries, these RO plants work on crossflow filtration method.

Working

The process of water purification is carried out in following steps

The feed water contains suspended particles and dissolved matter.

- The water is filtered through the sand filtration
- After the filtration, the water is then passed through activated carbon beds for the removal of foul odor, colo, and carbon
- Hard water is softened
- Addition of scale inhibitor
- Finally, Semi-automatic the water is passed through cartridge filters for removal of left our suspended particles

Application areas

• The Reverse Osmosis plant can be used in both commercial and industrial sectors.

Product Details:

Commercial Reverse Osmosis Plant removes all the impurities from water making it fit for varieties of commercial activities. Installed at commercial establishments like shopping malls and hospitals, the commercial RO plants are considered as the most cost effective water treatment system. It cleans the water from contaminants and removes non essential, metals, corrosive salts and chemicals present in the water.

Working:

Pre-Treatment:

• Clarification of water
• Sand filtration
• Water softening for reducing the hardness
• Water is passed through activated carbon filters
• Final removal of suspended particles using cartridge filters

Post-Treatment:

• Chlorination Systems

Application Areas:

The Commercial Reverse Osmosis Plants are widely used for:

• Purification of drinking water
• Dialysis
• Reef aquariums

Product Details:

Commercial Reverse Osmosis Plant removes all the impurities from water making it fit for varieties of commercial activities. Installed at commercial establishments like shopping malls and hospitals, the commercial RO plants are considered as the most cost effective water treatment system. It cleans the water from contaminants and removes non essential, metals, corrosive salts and chemicals present in the water.

Working
Pre-Treatment:

• Clarification of water
• Sand filtration
• Water softening for reducing the hardness
• Water is passed through activated carbon filters
• Final removal of suspended particles using cartridge filters

Post-Treatment:

• Oznonation
• Ultra-violet
• Chlorination Systems

Application areas:
The Commercial Reverse Osmosis Plants are widely used for:

• Purification of drinking water
• Dialysis
• Reef aquariums

Product Details:

Commercial Reverse Osmosis Plant removes all the impurities from water making it fit for varieties of commercial activities. Installed at commercial establishments like shopping malls and hospitals, the commercial RO plants are considered as the most cost effective water treatment system. It cleans the water from contaminants and removes non essential, metals, corrosive salts and chemicals present in the water.

Working
Pre-Treatment:

• Clarification of water
• Sand filtration
• Water softening for reducing the hardness
• Water is passed through activated carbon filters
• Final removal of suspended particles using cartridge filters

Post-Treatment:

• Oznonation
• Ultra-violet
• Chlorination Systems

Application areas:
The Commercial Reverse Osmosis Plants are widely used for:

• Purification of drinking water
• Dialysis
• Reef aquariums

.

Additional Information:

• Production Capacity: 5 per month
• Delivery Time: 1 week

Product Details:

We offer 1000 LPH F.R.P R.O Plantto our clients.
500 ltr. to 3000 lph

Product Details:



Additional Information:

• Production Capacity: 3000 LPH
• Delivery Time: 1 month
• Packaging Details: Plastic roll packing
